It starts with our Turbo Full Power 2.2 motor and MasterMind Turbo Control Unit (TCU), which provide Levo with a smooth and seamless amplification of your efforts—4x you power that lets you choose where to ride, and when you want to do it. Levo also shatters limitations when it comes to range, amplifying your effort for up to five hours of trail time. Now you can ride farther, and explore more, than ever before. And the optimized chassis boasts 150mm of custom-tuned rear suspension and adjustable geometry that delivers a stable and natural ride like no other. Because at the end of the day, it’s the ride that matters. Believe it.
Here’re where the gloves come off—the Levo Expert brings it with SRAM’s new AXS GX Eagle Transmission 12-speed drivetrain, dialed-in Rockshox Select Plus suspension, and a high-performing Roval HD Traverse wheelset.
- Levo’s fully integrated Turbo Full Power 2.2 motor, 700Wh battery, and advanced MasterMind Turbo Control Unit deliver category-leading 90 Nm of torque and 565 watts of power for up to five hours of ride time, empowering you to ride farther and faster than ever before.
- The MasterMind Turbo Control Unit is your information hub with customizable display fields, including the exact percentage of battery level, and it features our all-new MicroTune function to adjust power delivery in 10% increments, so you get exactly the support you need to experience precisely the ride you want.
- A dedicated mixed-wheel size design with a 27.5” wheel in the back and 29” up front delivers a nimble ride that carves circles around other full-power e-MTBs. A generous cockpit centers you on the bike, optimizing traction and corner control. The low bottom bracket, slack headtube angle and reduced fork offset keep things stable in the rough.
- Levo offers six distinct geometry settings, allowing you to easily dial-in its performance for any riding style andany terrain. Head tube angle can be adjusted between 63- and 65.5-degrees. Bottom bracket height can be fine-tuned up or down by 7mm.
- Levo’s 150mm of rear travel is supple on small bumps, devours square-edged hits without a twitch, eats massive G-outs for breakfast, yet still offers amazing pedal response and delivers your power to the ground with total efficiency.
- The Levo’s S-Sizing is based on what matters—rider size and style, not inseam. Six sizes, all with similar headtube lengths and standover, allow you to choose the size that best suits your individual style. Smaller S-Size numbers are going to be nimble and more flickable, while bigger S-Sizes deliver more stability and a roomier ride.
Specifications
FRAMESET
- Seat Binder
- Alloy, 38.6mm
- Frame
- FACT 11m full carbon, 29" front wheel, 27.5" rear wheel, full internal cable routing, 148mm spacing, fully sealed cartridge bearings, 150mm of travel, geo adjust head tube, geo adjust horst pivot
E-BIKE
- Wiring Harness
- Custom Specialized wiring harness
- Charger
- Custom charger, 42V4A w/ Rosenberger plug, 100-240V
- Motor
- Specialized 2.2 Custom RX Trail Tuned Motor
- Battery
- Specialized M3-700, Integrated battery, 700Wh
- UI/Remote
- Specialized MasterMind TCU, percentage of remaining charge, 120 possible display configurations, MicroTune assist adjustment, ANT+/Bluetooth®, w/Handlebar remote
SUSPENSION
- Fork
- Rockshox Zeb Select Plus, 29", S2-S6: 160mm, S1: 150mm
- Rear Shock
- S2-S6: Rockshox Vivid Select Plus, 210x55mm, S1: Rockshox Deluxe Select Plus, 210x52.5mm
COCKPIT
- Stem
- Alloy Trail Stem, 35mm bar bore
- Handlebars
- 6061 mtn bars, 35mm diameter, 8 degree back sweep, 6 degrees up sweep, 800mm width. S1/S2: 30mm rise, S3-S6: 40mm rise
- Saddle
- Specialized Bridge Comp with Mimic
- SeatPost
- PNW Loam Dropper, S1: 125mm, S2: 150mm, S3: 170mm, S4-S6: 200mm
- Grips
- Specialized Trail Grips
BRAKES
- Front Brake
- SRAM Maven Bronze, 220mm rotor, metallic pads
- Rear Brake
- SRAM Maven Bronze, 200mm rotor, metallic pads
DRIVETRAIN
- Crankset
- Praxis forged M30, custom offset, 160mm
- Chain
- SRAM GX Eagle Transmission Flattop Chain
- Chainrings
- SRAM Eagle Transmission 34t Steel, 104BCD
- Cassette
- SRAM GX Eagle Transmission Cassette, 12spd, 10-52t
- Shift Levers
- SRAM AXS POD Controller
- Rear Derailleur
- SRAM GX Eagle Transmission Derailleur
WHEELS & TIRES
- Front Tire
- Butcher, GRID GRAVITY casing, GRIPTON® T9 compound, 2Bliss Ready, 29x2.3"
- Rear Tire
- Eliminator, GRID GRAVITY casing, GRIPTON® T9/T7 compound, 27.5x2.3"
- Inner Tubes
- Standard, Presta Valve
- Front Wheel
- WH-TRAVERSE HD ALLOY 370 29 27.5 28H 32H;FS
- Rear Wheel
- WH-TRAVERSE HD ALLOY 370 29 27.5 28H 32H;FS
ACCESSORIES
- SWAT
- SWAT CC steerer tube integrated tool with chain tool and link
- Pedals
- PEDAL, TEST RIDE PEDALS PROVIDED BY SPECIALIZED
PRODUCT DETAILS
- Product ID
- 274925
WEIGHT
- Weight
- Weight Size
- S4
