SPECIFICATIONS
FRAMESET
- SWAT
- SWAT 4.0 internal downtube storage
- Frame
- FACT 11m carbon chassis and rear-end, Trail Geometry, SWAT™ Door integration, head tube angle adjustment, threaded BB, internal brake and dropper cable routing, 12x148mm dropouts, sealed cartridge bearing pivots, SRAM UDH compatible, 145mm of travel
- Seat Binder
- Alloy, 38.6mm
SUSPENSION
- Fork
- FOX FLOAT 36 Factory, GRIP X2 damper, HS and LS rebound and compression adjustment, 15x110mm QR axle, 44mm offset, S1:140mm of travel, S2-S6:150mm of travel
- Rear Shock
- FOX FLOAT Factory with Specialized GENIE Shock Tech, Ride Dynamics Trail Tune, 2-position lever w/3 setting Open mode tuning range, LSR adjustment, S1:210x52.5mm, S2-S6:210x55mm
COCKPIT
- Grips
- Deity Lockjaw
- Handlebars
- Roval Traverse SL Carbon, riser bar, 6-degree upsweep, 8-degree backsweep, 30mm rise, S1-S2: 780mm: S3-S6: 800mm
- Saddle
- Bridge Expert with MIMIC, Hollow Ti rails, S1-S2: 155mm, S3-S6: 143mm
- SeatPost
- Bike Yoke, Revive Max, 34.9, S1: 125mm, S2: 160mm, S3-S4: 185mm, S5-S6: 213mm
- Stem
- Industry 9 Moutain stem, 35mm clamp, 40mm length
BRAKES
- Front Brake
- SRAM Maven Silver, 4-piston caliper, hydraulic disc, 200mm HS2 Rotor
- Rear Brake
- SRAM Maven Silver, 4-piston caliper, hydraulic disc, S1-S2: 180mm, S3-S6: 200mm HS2 Rotor
DRIVETRAIN
- Bottom Bracket
- SRAM DUB, BSA 73mm Wide, Threaded
- Shift Levers
- SRAM AXS POD Controller
- Crankset
- SRAM X0 Eagle Crankset, 32T ring, Integrated Guard, 55mm Chainline, S1-S3:165mm, S4-S6: 170mm
- Chain
- SRAM X0 Eagle Transmission Flattop Chain
- Rear Derailleur
- SRAM X0 Eagle Transmission Derailleur
- Cassette
- SRAM X0 Eagle Transmission Cassette, 12spd, 10-52t
WHEELS & TIRES
- Rims
- Roval Traverse SL II, hookless carbon, 30mm inner width, tubeless ready, Front: 29, Rear: S1-S2: 27.5, S3- S6: 29
- Front Hub
- Industry 9 1/1, 15x110mm, 28h
- Front Tire
- Butcher, GRID TRAIL casing, GRIPTON® T9 compound, 2Bliss Ready, 29x2.3"
- Rear Hub
- Industry 9 1/1, 12x148mm, 28h
- Rear Tire
- Eliminator, GRID TRAIL casing, GRIPTON® T7 compound, 2Bliss Ready, S1-S2: 27.5x2.3, S3- S6: 29x2.3"
- Spokes
- Sapim D-Light
- Inner Tubes
- Standard, Presta valve
PRODUCT DETAILS
- Product ID
- 221403
WEIGHT
- Weight
- 13.99kg (30 lb, 13.5 oz)
- Weight Size
- S4
